Specifications
| Model | XLf 200 AW |
| Speaker Size | 12" |
| Max Output Power | 500W |
| RMS Output Power | 200W |
| Built-in Amplifier Type | Class D |
| Impedance | 2 Ω |
| Frequency Response | 20Hz-150Hz |
| S/N Ratio | >90dB |
| Low Pass Filter | 50Hz-150Hz |
| Operating Voltage | 14.4V(10V-16V) |
| Phase Switch | 0°/180° |
| Automatic ON/OFF | √ |
| Fuse | 20A |
| Bass Boost | 0-12dB |
| Subwoofer Cone Material | Fiber Glass |
| Subwoofer Magnet Material | Ferrite |
| Enclosure Material | Sealed Cast Aluminum Enclosure |
| Dimensions | 340x320x160mm |
| Net Weight | 9.8kg |
